The Shuttle LT is built to conquer the toughest climbs, unlock new loops and demonstrate dominance on every descent. Designed for those who crave the thrill of gravity-defying downhill, this enduro-inspired, long-travel eMTB is the ultimate all-day, anywhere companion. The Shuttle LT’s striking aesthetic pairs seamlessly with the Bosch Performance CX Race Limited Edition drive unit, unleashing a staggering 600 watts of max power. Backed by a robust 750wh battery at every build level, and expandable to 1000wh with the PowerMore range extender, it's ready for epic rides. The dw-link suspension system delivers unmatched traction and control on climbs, with rock-solid stability on descents.
FEATURES:
- Full Carbon Frame Constructed with Pivot's Proprietary Molding Technology
- Bosch Performance CX Race Limited Edition drive unit on every build level
- Power packed 750Wh Battery
- Bosch PowerMore 250 Range Extender Compatible
- Adjustable Geometry via Pivot Flip-Chip
- 170mm Fox 38 Fork
- 160mm Rear Wheel Travel
- 223mm Front and 203mm Rear Rotors
- Mixed-wheel setup
- Clean Internal Routing with Pivot Cable Port System
SPECS:
- Wheel Size: 29"/27.5"
- Frame: Shuttle LT
- Wheel Material: Alloy
- Rear Shock: Fox Factory Float X
- Fork: Fox Factory 38 29", 44mm offset, GRIP X2 - 170mm
- Headset: Pivot Precision Sealed Cartridge
- Rear Derailleur: Sram X0 Eagle Transmission 12-Speed
- Cassette: Sram GX 1275 Eagle Transmission 10-52t
- Shifter: Sram AXS Pod Controller
- Brakes: Shimano XT M8120 4-piston
- Crankset: Praxis Alloy eCranks E-MTB 34t - 160mm
- Handlebar: Phoenix Race Low Rise Carbon - 780mm (SM-MD), 800mm (LG-XL)
- Grips: Phoenix Factory Lock-On
- Stem: Phoenix Team Enduro/Trail - 45mm
- Seatpost: Fox Transfer Factory Series 150mm (SM), 175mm (MD-LG), 200mm (XL)
- Saddle: Phoenix WTB Volt Pro (Medium Width)
- Wheels: DT Swiss Hybrid HX1501, 30mm - Mixed 15x110 F/12x157 R
- Tires: Continental Kyrptotal-F 29" x 2.4" Soft Compound Enduro Casing; Continental Kyrptotal-R 27.5" x 2.6" Soft Compound Enduro Casing
- Rotors: Galfer Wave 6 Bolt - 223mm; Galfer Wave 6 Bolt - 203mm
- Chain: Sram GX Eagle Transmission Flattop 12-Speed
- Drive Unit: Bosch Performance CX Race Edition 750wh
